RunCam Phoenix 2-SPV3 FPV Camera for Drones

91
Not rated
RunCam
Magnifier
3953 phoenix3 1024x1024
  • 1 of 3
3953 1450 zoom 1695117831 PHOENIX2 V3 61374

Looking for a camera that will take your FPV experience to the next level? RunCam Phoenix 2-SPV3 is the perfect choice for FPV racing and freestyle enthusiasts who don’t want to compromise on image quality. With advanced technology and upgraded features, it delivers incredible image clarity in all lighting conditions, from bright sunlight to low-light flights.


  • $27,82 incl. VAT $22,99 / 1 pcs
  • On order
$22,99

Parameters

Category: FPV Cameras
Weight: 0.008 kg
Print
Garance doručení
nepoškozeného zboží
Přes 3000 výdejních míst
po celé ČR


Description

Equipped with a 1/2.8" Starlight CMOS sensor and 1500TVL resolution, you’ll capture every detail with stunning precision. The camera provides a wide 155° field of view (FOV) and excellent Global WDR (Wide Dynamic Range) for optimal contrast in varying light conditions. Additionally, the lightweight design (only 7.5g) and compact size make it easy to install on any drone.

Main Benefits:

  • High sensitivity (15000mV/Lux•sec) for great footage even in low light.
  • Global WDR for perfect balance between light and dark areas, even in rapidly changing light.
  • Wide 155° field of view for better situational awareness during your flights.
  • Choice between 4:3 and 16:9 formats for maximum flexibility.
  • Lightweight (7.5g) and compact for easy drone installation.

Specifications:

  • Image Sensor: 1/2.8" Starlight CMOS
  • Horizontal Resolution: 1500TVL
  • Field of View: 155° (Diagonal), 122° (Horizontal), 92° (Vertical)
  • Screen Format: 4:3 or 16:9
  • Shutter: Rolling Shutter
  • WDR: Global WDR for better dynamic range
  • Sensitivity: 15000mV/Lux•sec
  • Power Supply: 5-36V (Ideal for various drones)
  • Current Consumption: 120mA@5V / 220mA@12V
  • Housing Material: ABS for high durability
  • Menu Control: Cable Control
  • Weight: 7.5g
  • Dimensions: 19mm * 19mm * 21mm

Specifications:

Product Name RunCam Phoenix2 SP
Image Sensor 1/2.8" Starlight COMS Sensor
Horizontal 1500TVL
Lens FOV D:155° H:122° V:92° FOV D:138° H:122° V:68°
Screen Format 4:3 16:9
Mirror/Flip Available
Signal System NTSC/PAL
Shutter Rolling Shutter
Sensitivity 15000mV/Lux•sec
WDR Global WDR
Day/Night Color/BW
Menu Control Cable Control
Power DC 5-36V
Current 120mA@5V 220mA@12V
Housing Material ABS
Net Weight 7.5g
Dimensions 19mm*19mm*21mm
