Take your drone to the next level with the Foxeer 5.8G Reaper Extreme V2 transmitter – built for pilots who demand power, flexibility, and reliability. With up to 2.5W of power and 72 channels, including Raceband, this transmitter ensures a stable signal over long distances, making it perfect for both casual flying and competitive racing.

FOXEER_Reaper_Extreme_V2_2.5W_VTx_Frequency_Table1

Foxeer_Reaper_Extreme_V2_VTX_Manual


  • $72,48 incl. VAT $59,90 / 1 pcs
  • (>5 pcs) In stock
$59,90

Parameters

Category: Video transmitters
Weight: 0.013 kg
Print
Garance doručení
nepoškozeného zboží
Přes 3000 výdejních míst
po celé ČR


Description

With intuitive power control, you can easily switch between 5 different power levels to adjust for optimal performance. Whether you’re racing, flying for fun, or testing new setups, the Foxeer Reaper Extreme V2 has the power to keep you connected and in control.

Key Benefits:

  • High Power Output – Up to 2.5W for maximum range and a stable, clear signal.
  • Wide Channel Selection – 72 channels, including Raceband, for versatility and compatibility with other FPV equipment.
  • Pit Mode – Reduces interference during setup by minimizing output power.
  • Quick Power Adjustment – Easily switch between 5 power levels to suit your needs.
  • Tramp Protocol Compatibility – Automatically integrates with Betaflight and IRC Tramp for seamless setup and control.

Specifications:

  • Input Voltage: 9V ~ 36V
  • Output Voltage: 5V
  • Channels: 72 (including Raceband)
  • Power Levels: 25mW / 200mW / 500mW / 1.5W / 2.5W
  • Dimensions: 36mm x 27.5mm x 8mm
  • Weight: 13g (excluding antenna)
  • Consumption: 1.2A at 9V
  • Mounting Holes: 20mm x 20mm, M2, depth 2.8mm
  • Pit Mode: Double-click to turn on/off
  • Functions: WDR, Auto White Balance, 3DNR
  • Frequency Bands: A, B, E, F, R, H, L, U (including Raceband channels)
  • Control: Lock channels and power levels

Tips:

  • Pit Mode: Double-click the button to activate Pit mode for reduced power output during setup.
  • Unlocking Frequencies & Power: Long press the button to unlock all frequencies and power levels for full flexibility.

Specifications

Name Reaper Extreme V2
Input Voltage 9~36V
Output Voltage 5V
Channels 72CH
Power 25mW/200mW/500mW/1.5W/2.5W, red light flash 1/2/3/4/5 times correspondingly
Pit Double click to enter
Weight 13g
Mounting Hole 20*20mm M2 2.8mm depth
Size 36*27.5*8mm
Consumption 1.2A/9V
Package Includes 1 x VTx; 1 x silicon cable;



Band CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
Band A 5865 5845 5825 5805 5785 5765 5745 5725
Band B 5733 5752 5771 5790 5809 5828 5847 5866
Band E 5705 5685 5665 5645 5885 5905 5925 5945
Band F 5740 5760 5780 5800 5820 5840 5860 5880
Band R 5658 5695 5732 5769 5806 5843 5880 5917
Band H 5653 5693 5733 5773 5813 5853 5893 5933
Band L 5333 5373 5413 5453 5493 5533 5573 5613
Band U 5325 5348 5366 5384 5402 5420 5438 5456
Band O 5474 5492 5510 5528 5546 5564 5582 5600



Unlock the frequencies and power levels

Long press the "KEY" button until the Red LED (PWR) is constant on, off, then on again, release the button unlock the all frequencies and power levels, flashed Red LED means in unlocked status, constant Red LED means in locked status.



PIT Mode On/Off

Double-click the "KEY" button to turn on/off the PIT Mode. Red LED (PWR) off means PIT mode on; Red LED (PWR) on means PIT mode off。In PIT mode, VTx outpout extreme low power.

 Note:

If tramp cable is connected, button will not work, can not adjust frequency and power, controller will take over.

BetaFlight only can accept 64 channels at most, so the O band is removed from the frequency table default.
