Thanks to its compact design and lightweight (only 18.9g excluding antenna), it’s ideal for drones of all sizes, whether you’re flying in nature or in racing events. Plus, its smart output power self-check functionality and telemetry with the IRC Tramp protocol ensure maximum convenience and safety during your flight.
Key Benefits:
- Strong Transmission: Up to 1600mW for stable video signal even over long distances.
- Fast Frequency Locking: Minimal interference with other pilots.
- 40 Channels: Including Raceband for competitive use.
- Lightweight and Compact Design: Only 18.9g without antenna, ideal for drones.
- High Flexibility: 4 different output power settings (PIT, 25mW, 400mW, 800mW, 1600mW).
- Telemetry Support: IRC Tramp protocol for easy control and monitoring.
- Safety Check: Self-test functionality for output power monitoring.
Specifications:
- Input Voltage: 7V ~ 34V
- Interface: MMCX
- Power Levels: PIT/25mW/400mW/800mW/1600mW
- Channels: 40 (including Raceband)
- Mounting Pattern: 30.5x30.5mm/Φ3
- Weight: 18.9g (excluding antenna)
- VTX Telemetry: IRC Tramp
- RC Tramp VTX Table Values: 25mW/400mW/800mW/1600mW
Note: The VTX is set to 25mW by default. Higher power levels (above 25mW) require a HAM license or approval from local authorities. Please ensure you are using legal frequencies and set Betaflight VTX tables according to your region's regulations.
